●可配置各類測試機台、實現各種測試
安裝尺寸/Mounting Dimension
參數 | Specifications | 技術指标/Technique |
顯示窗口 | Display | 2.8寸TFT真彩色/LCD背光 |
可读性 | Readability | 1/90000 |
輸出線性 | Output linear | ＜0.002% |
綜合精度 | Comprehensive accuracy | 優于0.01% |
A/D轉換速度 | A/D Conversion speed | ≤1600次/秒 |
接受靈敏度 | Accept sensor | -3.6~+3.6 mV/V |
輸入負载 | Input load | 1～4只350Ω傳感器 |
輸出規格 | Output specification | ±10V / 0～10V / 4～20mA |
滿量程温度漂移 | Temp.effect on output | ≤10ppm /℃ |
零點温度漂移 | Temp.effect on zero | ≤10μV /℃ |
激勵電壓 | Excitation voltage | 5VDC |
電源供给 | Power supply | 24±5VDC |
整機功耗 | Power waste | ≤10W |
工作温度範圍 | Operation temp range | -20～70℃ |
单件重量 | Weight approx. | 0.5kg |
材料 | Material | 塑料外殼 |
防護等級 | IP Class | IP65 |
